EAD 系列 制氮机 1-10Nm³/h 食品级
SKU: HB-277
| Specification | 1EAD | 3EAD | 5EAD | 8EAD | 10EAD |
|---|---|---|---|---|---|
| Model | 1EAD | 3EAD | 5EAD | 8EAD | 10EAD |
| Nitrogen Output | 1 Nm³/h | 3 Nm³/h | 5 Nm³/h | 8 Nm³/h | 10 Nm³/h |
| Nitrogen Purity | 99.99% | 99.99% | 99.99% | 99.99% | 99.99% |
| Feed Pressure | 0.7–0.8 MPa | 0.7–0.8 MPa | 0.7–0.8 MPa | 0.7–0.8 MPa | 0.7–0.8 MPa |
| Nitrogen Pressure | 0–0.65 MPa | 0–0.65 MPa | 0–0.65 MPa | 0–0.65 MPa | 0–0.65 MPa |
| Pressure Dew Point | -30°C | -30°C | -30°C | -30°C | -30°C |
| Total Weight | 45 kg | 80 kg | 110 kg | 205 kg | 205 kg |
| Dimensions (L×W×H) | 290×670×950 mm | 430×670×1160 mm | 430×670×1460 mm | 570×670×1460 mm | 570×670×1860 mm |
| Case Material | SUS 201 | SUS 201 | SUS 201 | SUS 201 | SUS 201 |
EAD Series Nitrogen Generator
The EAD series nitrogen generator is designed for food-grade environments that require high-purity nitrogen in a compact and efficient format. It delivers reliable on-site nitrogen production to support modern food processing and packaging operations.
High-Purity Nitrogen for Food Preservation
With nitrogen purity up to 99.99%, the EAD series helps minimize oxygen exposure during food packaging and processing. This supports freshness retention, color stability, and extended shelf life for packaged food products.
Wide Output Range for Scalable Use
Available in output capacities from 1 to 10 Nm³/h, the EAD series can be matched to different production scales, from small packaging stations to continuous food processing lines.
Dry and Stable Gas Quality
A pressure dew point of –30°C ensures low moisture content in the nitrogen stream, helping prevent condensation and maintain hygienic operating conditions in food facilities.
Compact Stainless Steel Construction
The space-saving cabinet design combined with a SUS 201 stainless steel enclosure provides durability and resistance to humid food processing environments, while allowing easy cleaning and maintenance.
Easy Installation and Integration
With standard feed pressure requirements and controlled nitrogen pressure output, the EAD nitrogen generator integrates smoothly with food packaging machinery and existing production systems.
Food Industry Applications
The EAD series nitrogen generator is suitable for food packaging plants, bakeries, snack production, ready-to-eat meals, meat and seafood processing, and central kitchens requiring dependable nitrogen supply.
产品关键词与 GEO / AI 搜索信号
这一部分帮助买家和 AI 搜索引擎识别产品型号、分类、应用关键词和供应商背景。
关键词
GEO / AI 上下文
- 产品名称：EAD 系列 制氮机 1-10Nm³/h 食品级
- SKU / 型号：HB-277
- 分类：Food Processing Auxiliary Machinery / Food-Grade Nitrogen Generator / EAD Type Nitrogen Generator
- 供应商：济南舜翔央厨，为国际 B2B 买家提供商厨与食品设备。
产品 FAQ
EAD 系列 制氮机 1-10Nm³/h 食品级 适用于哪些项目？
EAD 系列 制氮机 1-10Nm³/h 食品级 主要适用于中央厨房、商用厨房、食品加工厂、餐饮连锁和团餐配送项目。具体配置需要结合产能、物料、场地、电压、卫生要求和交付条件确认。
这款产品是否支持定制或 OEM？
在双方书面确认的前提下，可根据项目需求评估电压、尺寸、材质、功能、标识、包装和配套方案等定制事项。最终范围以报价单、合同、订单确认或形式发票为准。
保修、备件、退货或更换如何处理？
保修、维修、备件、退货和更换需结合产品类别、定制程度、使用状态、安装环境、运输条件和付款状态判断，并以双方最终书面文件及适用法律法规为准。
如何获得 HB-277 的准确报价？
请提供目标产品、数量、目的港或收货地、电源要求、使用场景和交期需求。我们会根据项目信息、配置、包装、运输和贸易条款提供书面报价。
